STERILIZED MILK
灭菌奶
工艺介绍：
◆工艺：5℃→65℃均质→95℃30S→140℃4S→25℃
◆冰水 1：1(≤2℃备用) 冷却水 1：1（30℃备用）
Technology introduction:
◆Technology: 5℃→65℃Homogenization→95℃ 30S→140℃ 4S→25℃
◆Ice water 1:1 (≤2℃ spare) Cooling water 1:1（30℃ spare）
技术参数 Technical Parameter
| 型号规格 model and specification | 能力capacity | 蒸汽能耗steam consumption | 蒸汽压力steam pressure | 电功率power | 整体式外形尺寸outline dimensions of integral type | 分体式外形尺寸outline dimensions of split type | 重量weight | 管径pipe diameter | | t/h | kg/h | bar | kw | l*w*h | l*w*h | kg | 物料material | 蒸汽steam | 介质medium | | TG-UHT-1MQJ | 1 | 40 | 6.0 | 4.0 | 3.3*1.6*1.8 | | 1960 | 25 | DN25 | 25 | | TG-UHT-1.5MQJ | 1.5 | 60 | 6.0 | 4.0 | 3.3*1.6*1.8 | | 1960 | 25 | DN25 | 25 | | TG-UHT-2MQJ | 2 | 80 | 6.0 | 6.0 | 3.5*1.8*2.0 | | 2160 | 38 | DN25 | 38 | | TG-UHT-3MQJ | 3 | 120 | 6.0 | 6.0 | 3.5*1.8*2.0 | | 2420 | 38 | DN32 | 38 | | TG-UHT-4MQJ | 4 | 160 | 6.0 | 7.0 | 4.5*2.0*2.0 | 6.5*0.9*1.4 | 2570 | 38 | DN32 | 38 | | TG-UHT-5MQJ | 5 | 200 | 6.0 | 7.0 | 4.5*1.8*2.0 | 6.5*0.9*1.4 | 2940 | 51 | DN40 | 51 | | TG-UHT-6MQJ | 6 | 240 | 6.0 | 7.0 | 4.5*2.0*2.2 | 6.5*0.9*1.4 | 3300 | 51 | DN40 | 51 | | TG-UHT-8MQJ | 8 | 320 | 6.0 | 11.0 | 4.5*2.0*2.2 | 6.5*0.9*1.4 | 3700 | 51 | DN50 | 51 | | TG-UHT-10MQJ | 10 | 400 | 6.0 | 11.0 | 4.5*2.0*2.2 | 6.5*0.9*1.4 | 4200 | 51 | DN50 | 51 | |
